Takane Westminster Chime Pendulum Dials < 20mm

Stock Code:
QTCP.30
RRP:
$99.00
Your Price:
$99.00
Stock Level:
5 Available
Make an Enquiry

Details

Description

Quartz

Part Number : QTCP.30

Description : Quartz Time, Chime and Pendulum Movement 30mm
(Max. Dial Thickness 20mm)

Size : 130 mm Wide x 75 mm Wide x 30 mm Thick
Weight : 90 Grams
Material : ABS Plastic Case

Features : Time ( Hours, Minutes, Seconds )
Westminster Chimes feature
Pendulum Feature
Time / Chime Incremental Adjustment

Hand shaft is 30 mm long
Maximum dial thickness to trap is 20mm or less
Dial hole should be a minimum of 10mm

Uses : These Parts
Euroshaft Design Specifications
Hour hand hole bush is 5mm dia
Minute hand hole is slotted 4mm dia slotted is 3mm

Hand nut thread is metric 4mm fine with pitch of 0.5mm
Locking nut thread is metric 8mm with pitch of 0.75mm

Suits : These Parts
HQ. Euroshaft Hands
QPEND.70 Quartz Pendulum
E122.0000 Battery ( "C" or LR14 )

Notes : Hands purchased separately
