Time & Tide for dials < 6mm - Press Fit

Stock Code:

QTIDE.18

RRP:

$55.00

Your Price:

$55.00

Stock Level:

10 Available

Quantity:

Make an Enquiry

Details

Description

"Tide" Quartz

Part Number : QTIDE.18

Description : Quartz Time & Tide Movement 18 mm
(Max. Dial Thickness 6 mm)

Size : 73 mm High x 55 mm Wide x 25 mm Thick
Weight : 60 Grams
Material : ABS Plastic Case

Features : Time ( Hours, Minutes, Seconds )
Also Drives Tide Hand
Hand shaft is 18 mm long total
Max dial thickness to trap is 6 mm or less
Dial hole should be a minimum of 12 mm
Non Stock Push fit Hands supplied with Movement.

Shaft Stepped at 10mm,12 mm,15 mm (measured from Base Plate)

Uses : These Parts
Press Fit Design Specifications
Hour hand hole bush is 5 mm dia
Minute hand hole is 3.2 mm dia
Second Hand feature pin shaft size: 0.80mm
Tide Hand Hole is 7.3mm dia

Suits : These Parts
E122.0000 Battery ( "AA" or LR6 )

Straight Black Hands 120/90mm
Straight Red Second Hand 110mm
Stright Blue Tide Hand 80mm

Notes : This Movement Supplied with Hands

See : Other Quartz

Downloads

Download Installation Guide
